As a traditional lifting and pulling device,15 tons winch machine is still used in many occasions like construction site, bridge building project, even electricity project. Though in today’s construction site, it seems that tower crane and trunk crane are more popular, winch machine still has irreplaceable advantages. The reasons why it is used by many building site are as following:
Firstly, winch machine is suitable for medium and light duty loads transport, it is unnecessary for many occasions to use large and super large lifting device. Winch machine is quite fit for those assembling project. Secondly, winch machine save lots of cost than tower crane. Winch is short in size, and the compact structure helps saving huge money. So if you want to save cost, try a winch. Thirdly, winch machines of toady have various series. Each type has their unique function, you can choose what you want. You can choose the power system, driven system and any tons winch you want. Taking our 15 tons winch for example, you can choose hydraulic power or electricity power system for your winch. And we provide you different types of winch according to their ability and function. The brief introduction follows next:
Features of our 15 tons winch
We provide you three types of 15 tons winch, each of them has their unique function, they are AQ-JM 15 tons winch, AQ-JMM 15 tons winch and 15 tons mine winch.
AQ-JM 15 tons winches
AQ-JM 15 Tons Winch
Loading capacity: 30 t;
Wire rope capacity: 20~3600 m;
Working speed: 5~20 m/min;(single speed and dual speed)
Power supply:
220-690V,50/60HZ,3Phase;
This winch can be used in many occasions, if you want to use a winch in building site, bridge building project, installer or small and medium electricity assembling project, AQ-JM type winch will be your best choice. And it is quite suit for high accurate task, and its slow speed makes lifting and pulling transport stable. Moreover, JM winch is able to use on ships or coast, it plays an anchoring and mooring role in those occasions.
AQ-JMM 15 tons winches
AQ-JMM 15 Tons Winch
Loading capacity: 30 t;
Wire rope capacity: 20~5000 m;
Working speed: 5~20 m/min;
Power supply:
220-690V,50/60HZ,3Phase
This winch is special designed for large and super large project. If you want to transport long steel structure, steel winch rope or chain of very long distance, AQ-JMM winch will be your best choice. This winch can transport loads constantly, and the winch can keep stable in the whole transporting process.
15 tons mine winches
15 Tons Mine Winch
Speed: 1.3 m/s
Width: 800mm
Lifting material: 15 KN
Max.diameter: 14 mm
Accept Your Customization
Mine winch is used inside or outside a metal and non-metal mine. You can place your mine winch in a copper mine, zinc mine, coal mine or iron mine. And if you have any explosive proof function of your winch, we will design an explosive proof mine winch according to your requirements.
| Technical Parameter of AQ-JM 15 Tons Winch | ||||||||
| Model | Rated load |
Rated speed |
Rope capacity |
Rope diameter |
Motor type |
Motor power |
Overall Dimensions |
Overall weight |
| KN | m/min | m | mm | KW | mm | KG | ||
| AQ-JM1 | 10 | 15 | 100 | 9.3 | Y112M-6 | 3 | 620x701x417 | 270 |
| AQ-JM1.6 | 16 | 16 | 150 | 12.5 | Y132M-6 | 5.5 | 945x996x570 | 500 |
| AQ-JM2 | 20 | 16 | 150 | 13 | Y160M-6 | 7.5 | 945x996x570 | 550 |
| AQ-JM3.2 | 32 | 9.5 | 150 | 15.5 | YZR160M-6 | 7.5 | 1430x1160x910 | 1100 |
| AQ-JM3.2B | 32 | 12 | 195 | 15.5 | YZR160M-6 | 7.5 | 1082x1014x610 | 536 |
| AQ-JM5 | 50 | 10 | 270 | 21.5 | YZR160L-6 | 11 | 1235x1230x805 | 1560 |
| AQ-JM5B | 50 | 9.5 | 200 | 21.5 | YZR160L-6 | 11 | 1620x1260x945 | 1800 |
| AQ-JM5C | 50 | 9.5 | 250 | 21.5 | YZR160L-6 | 11 | 1235x1230x805 | 1800 |
| AQ-JM5D | 50 | 15 | 250 | 21.5 | YZR180L-6 | 15 | 1235x1230x805 | 1850 |
| AQ-JM5E | 50 | 20 | 250 | 21.5 | YZR200L-6 | 22 | 1235x1230x805 | 2000 |
| AQ-JM6 | 60 | 9.5 | 270 | 24 | YZR180L-6 | 15 | 1235x1509x805 | 1800 |
| AQ-JM8 | 80 | 8 | 250 | 26 | YZR180L-6 | 15 | 2090x1475x956 | 2900 |
| AQ-JM8B | 80 | 9.5 | 350 | 26 | YZR180L-6 | 15 | 1075x1598x985 | 2650 |
| AQ-JM10 | 100 | 8 | 170 | 30 | YZR200L-6 | 22 | 2090x1475x956 | 3000 |
| AQ-JM10B | 100 | 9.5 | 250 | 30 | YZR200L-6 | 22 | 1705x2200x985 | 3500 |
| AQ-JM12.5 | 125 | 8 | 300 | 34 | YZR225M-6 | 30 | 2880x2200x1550 | 5000 |
| AQ-JM13.5 | 135 | 0-5 | 290 | 28 | YZR225S-8 | 22 | 2990x2363x1650 | 6500 |
| AQ-JM16 | 160 | 10 | 500 | 37 | YZR250M2-8 | 37 | 3750x2400x1850 | 8800 |
| AQ-JM20 | 200 | 10 | 600 | 43 | YZR280S-8 | 45 | 3950x2560x1950 | 9900 |
| AQ-JM25 | 225 | 9 | 700 | 48 | YZR280M-8 | 55 | 4350x2800x2030 | 13500 |
| AQ-JM32 | 320 | 9 | 700 | 56 | YZR135S-8 | 75 | 4500x2850x2100 | 14800 |
| AQ-JM50 | 500 | 9 | 800 | 65 | YZR315M-8 | 90 | 4930x3050x2250 | 19500 |
| AQ-JM65 | 650 | 10.5 | 3600 | 64 | LA8315-8AB | 160 | 5900x4680x3200 | 46000 |
| Technical Parameter of AQ-JMM Series 15 Tons Winch | ||||||||
| Model | Rated load |
Rated speed |
Rope capacity |
Rope diameter |
Motor type |
Motor power |
Overall Dimensions |
Overall weight |
| KN | m/min | m | mm | KW | mm | KG | ||
| AQ-JMM10 | 100 | 10 | 4800 | 30 | YZR225M-6 | 30 | 1980x2650x850 | 6000 |
| AQ-JMM16 | 160 | 11 | 1000 | 34.5 | YZR225M-6 | 45 | 3350x1920x1320 | 9500 |
| AQ-JMM20 | 200 | 11 | 3600 | 39 | YZR280S-6 | 55 | 3500x1960x1320 | 10000 |
| AQ-JMM32 | 320 | 10 | 3200 | 52 | YZR280M-6 | 75 | 4330x2350x1760 | 16000 |
| AQ-JMM55 | 550 | 5 | 2000 | 60 | YZR280M-6 | 75 | 5000x2800x1900 | 22000 |
| Model | TYPE | Tensile force of wire rope |
Wire rope |
Overall dimension | The whole weight |
|||||||||
| No. | Diameter | Width | Lifting man |
Lifting material |
Max.diameter | Breaking force |
Speed | Legnth | Width | Height | ||||
| Pcs | mm | KN | mm | KN | m/s | mm | kg | |||||||
| JTK-0.8×0.6 | 1 | 800 | 600 | / | 15 | 14 | 97.5 | 1.3 | 3×2.2×1.3 | 2100 | ||||
| JTK-1.0×0.6 | 1000 | 800 | 15 | 12 | 97.5 | 1.7 | 3.4×2.1×1.5 | 3300 | ||||||
| JTP-1.2×1 | 1 | 1200 | 1000 | 15 | 21 | 14 | 137 | 2/2.5 | 5x5x2.75 | 9562 | ||||
| JTP-1.2×1.2 | 1200 | 1.5/1.9 | 5.2x5x2.75 | 9585 | ||||||||||
| 2JTP-1.2×0.8 | 2 | 1200 | 800 | 15 | 21 | 14 | 137 | 2.5/3.0 | 6.1x5x2.75 | 11700 | ||||
| 2JTP-1.2×1.0 | 1000 | 1.5/1.9 | 6.1x5x2.75 | 11900 | ||||||||||
| JTP-1.6×1.2 | 1 | 1600 | 1200 | 31 | 42 | 20 | 279 | 2/2.5 | 6.4×5.4×2.9 | 13538 | ||||
| JTP-1.6×1.5 | 1500 | 1.5/1.9 | 6.7×5.4×2.9 | 14128 | ||||||||||
| 2JTP-1.6×0.9 | 2 | 1600 | 900 | 31 | 42 | 20 | 279 | 3.0/4.0 | 7.1×5.4×2.9 | 16760 | ||||
| 2JTP-1.6×1.2 | 1200 | 2/2.5 | 7.4×5.4×2.9 | 17370 | ||||||||||
| JK-2×1.5 | 1 | 2000 | 1500 | 44 | 60 | 24 | 396.5 | 4.0/5.0 | 8.15×6.86×2.75 | 24955 | ||||
| JK-2×1.8 | 1800 | 2.5/3.2 | 8.4×6.86×2.75 | 25396 | ||||||||||
| 2JK-2×1 | 2 | 2000 | 1000 | 44 | 61 | 24 | 396.5 | 4.0/7.0 | 9.48×6.97×2.75 | 28955 | ||||
| 2JK-2×1.25 | 1250 | 2.5/3.2 | 9.73×6.97×2.75 | 30355 | ||||||||||
| JK-2.5×2 | 1 | 2500 | 2000 | 69 | 90 | 30 | 621 | 3.8/4.8 | 10.26×9.12×3.05 | 35200 | ||||
| JK-2.5×2.3 | 2300 | 3.0/3.4 | 10.56×9.12×3.05 | 36040 | ||||||||||
| 2JK-2.5×1.2 | 2 | 2500 | 1200 | 69 | 83 | 30 | 621 | 8.7/4.9 | 11.56×9.12×3.05 | 46325 | ||||
| 2JK-2.5×1.5 | 1500 | 2.5/4.0 | 11.86×9.12×3.45 | 47752 | ||||||||||
| JK-3×2.2 | 1 | 2500 | 2200 | 100 | 130 | 36 | 900 | 4.6/5.9 | 12.4×10.8×2.85 | 52540 | ||||
| JK-3×2.5 | 2500 | 3.0/4.1 | ||||||||||||
| JK-3.5×2.5 | 1 | 3500 | 2500 | 136 | 170 | 42 | 1230 | 5.4/6.7 | 14.18×10.65×3.95 | 73940 | ||||
| JK-3.5×2.8 | 3.5/4.8 | |||||||||||||
| 2JK-3×1.5 | 2 | 3000 | 1500 | 100 | 135 | 36 | 900 | 5.9/10.0 | 14.1×10.8×3.45 | 58750 | ||||
| 2JK-3×1.8 | 1800 | 3.0/4.7 | 14.7×10.8×3.45 | 60250 | ||||||||||
| 2JK-3.5×1.7 | 2 | 3500 | 1700 | 136 | 170 | 42 | 1230 | 6.7/12.0 | 15.9×10.65×3.95 | 77830 | ||||
| 2JK-3.5×2.1 | 2100 | 3.5/5.3 | 16.7×10.65×3.95 | 79630 | ||||||||||
