Small hydraulic winch is the necessary part of horizontal movement transportation. It lift up and transport loads match with auxiliary equipment like derrick, mask and pulley block. Small hydraulic winches refer to winch machine that powered by hydraulic pressure, and those compact hoisting devices are able to pull, drag and lift heavy loads.
Electricity power winch still plays an important role on construction site, while it has some shortcomings, hydraulic winch make up this disadvantage, and becoming more and more popular on modern factory and construction site.
Features of Ellsen small hydraulic winch
JM Small Hydraulic Winch
Loading capacity: 0.5~200 t;
Wire rope capacity: 20~3600 m;
Working speed: 5~20 m/min;(single speed and dual speed)
As a new type winch machine, hydraulic winch is an ideal innovation. This winch adopts hydraulic transmission and two stage planetary gear reduction. For brake system, Ellsen adopts friction clutch coupling. Hydraulic winch has a stable and reliable transmission, and it consumes less power. This winch includes winch drum, wire rope and holder. The working process as following: single stage and two stage reducer are installed in winch drum, primary sun gear shaft connects with the output shaft with motor; two stage reducer installed on the planetary mount of single stage reducer, inner gear of two stage reducer connects the inner side of single stage reduce; inner gear of drum meshes outer gear of secondary stage reducer; brake cylinder is set on the inner side of winch drum; friction clutch coupling consists of oil cylinder, spring and internal and external friction disc.
Advantages of hydraulic winches
Stable and reliable. This winch is stable and has good balance ability.
Less power consumption. Advanced technology saves power consumption.
Short in size. Compact and design saves space.
Light deadweight. Quality and solid material saves unnecessary part.
Compact structure. Scientific design saves useless part.
Easy to operate and maintain.
Safety. Safety brake.
Functional. Different types of winches and multi-function design can meet your special need.
