Ellsen power winch for sale

Power Winch

Our group provides you many types of winch machines, and you can choose what you want based on your need. Power winches have many series. Generally speaking, all types winch can be designed as the two power system including electricity power winch and hydraulic power winch. You can choose your power system according to your needs.

Basically, we adopts electricity to construction winch (winch is used in land). And for winch that used in ship or marine, we usually adopts hydraulic power. You can also choose the hydraulic power for your winch used in ship or coast. If you have any special need, please contact us, and we will make your special winch machine design.

Different Types of Power Winch

There are many types of power winch, and next is the brief introduction. If you want any type, please click the inquiry frame to get yourself one.

  • AQ-JM type power winch has two function. When it is used in land, it can pull, lift and drag heavy loads. And when it is used in ship or deck, it is to anchor and moor. If you want to use your power winch in both land and ship, JM power winch is your best choice.
  • AQ-JK power winch machine can be used in derrick and crane as main lifting device. If you have any need to match your power winch with derrick and portable frame, try JK winch.
  • AQ-JKL power winch has many advantages, it can contribute to your lifting and pulling task in construction site and installer. Meanwhile, it can do pile task in bridge building project and building site.
  • AQ-JKD power adopts planetary transmission, which makes its size shorter and compacter.
  • And AQ-JMM power winch is suitable for super large and large project. Its winch rope speed is constant, and the lifting activity is stable.

strong power winch for sale
Durable AQ-JM power winch


AQ-JM Power Winch

Loading capacity: 0.5~200 t;
Wire rope capacity: 20~3600 m;
Working speed: 5~20 m/min;(single speed and dual speed)
Power supply:
220-690V,50/60HZ,3Phase;

Get a Free Quote

Ellsen power winch for sale
power winch


AQ-JK Power Winch

Loading capacity: 0.5~60 t;
Wire rope capacity: 20~500 m;
Working speed: 20~35 m/min; (single speed and dual speed)
Power supply:
220-690V,50/60HZ,3Phase;

Get a Free Quote

power winch for sale
AQ-JKL power winch


AQ-JKL Power Winch

Loading capacity: 1~10t;
Wire rope capacity: 20~500 m;
Working speed: 20~36 m/min;
Power supply:
220-690V,50/60HZ,3Phase;

Get a Free Quote

power winch for sale
AQ-JKD power winch


AQ-JKD Power Winch

Loading capacity: 0.75-2 t;
Wire rope capacity: 20~200 m;
Working speed: 20~35 m/min;
Power supply:
220-690V,50/60HZ,3Phase;

Get a Free Quote

power winch for sale
AQ- JMM power winch


AQ-JMM Power Winch

Loading capacity: 0.5~100t;
Wire rope capacity: 20~5000 m;
Working speed: 5~20 m/min;
Power supply:
220-690V,50/60HZ,3Phase

Get a Free Quote

Why Choose our winches?

Our group will be your best choice of power, you will never regret your choice. Firstly, we are professional, as the leading force of China’s winch industry, we have many experiences. And we will solve your problems when choosing winch machine. Then, we will give you best quality winch machine with good price. Interested in our winch machine? Why not choose one to free your hand?

Technical Parameter of AQ-JM Series  Power Winch
Model Rated
load
Rated
speed
Rope
capacity
Rope
diameter
Motor
type
Motor
power
Overall
Dimensions
Overall
weight
KN m/min m mm KW mm KG
AQ-JM1 10 15 100 9.3 Y112M-6 3 620x701x417 270
AQ-JM1.6 16 16 150 12.5 Y132M-6 5.5 945x996x570 500
AQ-JM2 20 16 150 13 Y160M-6 7.5 945x996x570 550
AQ-JM3.2 32 9.5 150 15.5 YZR160M-6 7.5 1430x1160x910 1100
AQ-JM3.2B 32 12 195 15.5 YZR160M-6 7.5 1082x1014x610 536
AQ-JM5 50 10 270 21.5 YZR160L-6 11 1235x1230x805 1560
AQ-JM5B 50 9.5 200 21.5 YZR160L-6 11 1620x1260x945 1800
AQ-JM5C 50 9.5 250 21.5 YZR160L-6 11 1235x1230x805 1800
AQ-JM5D 50 15 250 21.5 YZR180L-6 15 1235x1230x805 1850
AQ-JM5E 50 20 250 21.5 YZR200L-6 22 1235x1230x805 2000
AQ-JM6 60 9.5 270 24 YZR180L-6 15 1235x1509x805 1800
AQ-JM8 80 8 250 26 YZR180L-6 15 2090x1475x956 2900
AQ-JM8B 80 9.5 350 26 YZR180L-6 15 1075x1598x985 2650
AQ-JM10 100 8 170 30 YZR200L-6 22 2090x1475x956 3000
AQ-JM10B 100 9.5 250 30 YZR200L-6 22 1705x2200x985 3500
AQ-JM12.5 125 8 300 34 YZR225M-6 30 2880x2200x1550 5000
AQ-JM13.5 135 0-5 290 28 YZR225S-8 22 2990x2363x1650 6500
AQ-JM16 160 10 500 37 YZR250M2-8 37 3750x2400x1850 8800
AQ-JM20 200 10 600 43 YZR280S-8 45 3950x2560x1950 9900
AQ-JM25 225 9 700 48 YZR280M-8 55 4350x2800x2030 13500
AQ-JM32 320 9 700 56 YZR135S-8 75 4500x2850x2100 14800
AQ-JM50 500 9 800 65 YZR315M-8 90 4930x3050x2250 19500
AQ-JM65 650 10.5 3600 64 LA8315-8AB 160 5900x4680x3200 46000
Technical Parameter of AQ-JK series  Power Winch
Model Rated
load
Rated
speed
Rope
capacity
Rope
diameter
Motor
type
Motor
power
Overall
Dimensions
Overall
weight
KN m/min m mm KW mm KG
AQ-JK0.5 5 22 190 7.7 Y100L-4 3 620x701x417 200
AQ-JK1 10 22 100 9.3 Y112M-4 4 620x701x417 300
AQ-JK1.6 16 24 150 12.5 Y132S-4 5.5 945x996x570 500
AQ-JK2 20 24 150 13 Y132M-4 7.5 945x996x570 550
AQ-JK3.2 32 25 290 15.5 YZR180L-6 15 1325x1335x840 1011
AQ-JK3.2B 32 30 250 15.5 YZR200L-6 22 1900x1738x985 1500
AQ-JK5 50 30 300 21.5 YZR225M-6 30 1900x1620x985 2050
AQ-JK5B 50 25 210 21.5 YZR225M-8 22 2250x2250x1300 2264
AQ-JK8 80 25 160 26 YZR280S-8 45 1533x1985x1045 3000
AQ-JK10 100 30 300 30 YZR315S-8 55 2250x2500x1300 5100
Technical Parameter of AQ-JKL series  Power Winch
Model Rated
load
Rated
speed
Rope
capacity
Rope
diameter
Motor
type
Motor
power
Overall
Dimensions
Overall
weight
KN m/min m mm KW mm KG
AQ-JKL2 20 30 150 13 Y180L-6 15 1370x1650x1210 1200
AQ-JKL3 30 30 200 15 Y200L-6 22 1690x1740x1200 1800
AQ-JKL5 50 30 250 21 Y225S-6 37 2300x2100x1650 3000
AQ-JKL6 60 36 250 24 Y280S-6 45 2350x2100x1650 3200
AQ-JKL8 80 29 250 26 Y280M-6 55 2440x2500x1800 5500
AQ-JKL10 100 29 250 28 Y315S-6 75 2590x2540x1800 5800
Technical Parameter of AQ-JKD Series  Power Winch
Model Rated load Rope capacity Rope diameter Motor power Overall Dimensions Overall weight
KN m mm KW mm KG
AQ-JKD0.75 7.5 100 9.3 3 900x340x400 165
AQ-JKD1.25 12.5 120 11 7.5 1140x400x450 315
AQ-JKD1.60 16 160 12.5 7.5 1200x400x480 350
AQ-JKD2.0 20 190 13 13 1400x470x548 510
Technical Parameter of AQ-JMM Series  Power Winch
Model Rated
load
Rated
speed
Rope
capacity
Rope
diameter
Motor
type
Motor
power
Overall
Dimensions
Overall
weight
KN m/min m mm KW mm KG
AQ-JMM10 100 10 4800 30 YZR225M-6 30 1980x2650x850 6000
AQ-JMM16 160 11 1000 34.5 YZR225M-6 45 3350x1920x1320 9500
AQ-JMM20 200 11 3600 39 YZR280S-6 55 3500x1960x1320 10000
AQ-JMM32 320 10 3200 52 YZR280M-6 75 4330x2350x1760 16000
AQ-JMM55 550 5 2000 60 YZR280M-6 75 5000x2800x1900 22000
